| Item | Unit | VNL40H | VNL60H | VNL80H | VNL80HK | VNL100H |
|---|---|---|---|---|---|---|
| Max. Swing over Bed | mm | Φ620 | Φ800 | Φ930 | Φ1000 | Φ1000 |
| Max. Turning Dia. | mm | Φ600 | Φ780 | Φ850 | Φ800 | Φ1000 |
| Max. Cutting Height | mm | 460 | 610 | 770 | 600 | 800 |
| Max. Workpiece Weight | kg | / | / | / | 2000 | / |
| Travel X/Z | mm | 350/500 | 420/620 | 480/780 | 685/600 | 520/880 |
| Rapid Traverse X/Z | m/min | 20/20 | 20/20 | 20/20 | 12/10 | 12/12 |
| Spindle Motor Power | kW | 15/18.5 | 18.5/22 | 22/30 | 15/18.5 | 18.5/22 |
| Worktable Dia. | inch/mm | 12" (Hydraulic Chuck) | 15" (Hydraulic Chuck) | 18" (Hydraulic Chuck) | Φ630 | 21" (Hydraulic Chuck) |
| Max. Worktable Rotate Speed | r/min | 2500 | 1500/2000 | 1500/2000 | 600 | 1500 |
| Max. Worktable Torque | N.m | 573/544 | 716/913 | 1345 | 3200 | 2083/3650 |
| Tool Position | - | 8(Horizontal) [6(Vertical)] | 12(Horizontal) [6(Vertical)] | 12(Horizontal) [6(Vertical)] | 8(Tool Magazine) | 12(Horizontal) [6(Vertical)] |
| Turning Tool Shank | mm | 25×25 | 32×32 | 32×32 | 32×32 | 32×32 |
| Driving Type | - | Hydraulic [Servo] | Hydraulic [Servo] | Hydraulic [Servo] | Electrical | Hydraulic [Servo] |
| CNC Controller | - | NEWAY FANUC [SIEMENS] | ||||
| Auto Chip Conveyer | - | Rear-way [Side-way] | Rear-way [Side-way] | Rear-way [Side-way] | Rear-way | Rear-way [Side-way] |
| Machine Weight | kg | 6500 | 8000 | 9500 | 12000 | 12000 |
