Reliable Choice for Efficiency and Effortless Operation
High-Speed Cutting
Equipped with 1.5G acceleration and a lightweight yet robust structure, the A Series maximizes efficiency and the value created every second.
Diverse Options
The A Series caters to varied business needs, offering power ranges from 1.5kW to 60kW and sizes spanning 3048mm×1524mm to 14000mm×3100mm..
Easy Operation
The intuitive controls and smart features of the A Series simplify laser cutting workflows and maintenance, making it accessible for all skill levels.
Efficiency Improved Time-Valued
It adopts high-performance bus servo motors to achieve the absolute leading dynamic performance (compared with similar products in the market). Significantly improving processing efficiency to ensure that every second you invest is creating value.
1.5G
Maximum acceleration up to
20%
Overall Performance
Note: The “Overall Performance Improved by 20%” mentioned above is relative to Bodor’s previous-generation product.
Find the perfect product for you!
| Model | Working Area | Max. Lineage Speed | Max. Acceleration | Head Type | Positioning Accuracy | Repositioning Accuracy | Table Load Bearing |
|---|---|---|---|---|---|---|---|
| A3 | 3048×1524mm | 100m/min | 1.5G | 100mm, 2 units head | ±0.05mm/m | ±0.03mm | 1500-6000W: 911kg |
| A4 | 4000×1524mm | 100m/min | 1.5G | 100mm, 2 units head | ±0.05mm/m | ±0.03mm | 1500-6000W: 1196kg |
| A4Plus | 4000×2000mm | 100m/min | 1.5G | 100mm, 2 units head | ±0.05mm/m | ±0.03mm | 1500-6000W: 1570kg |
| A6 | 6100×1524mm | 100m/min | 1.5G | 100mm, 2 tools Manual | ±0.05mm/m | ±0.03mm | 1500-6000W: 1824kg 12000W: 2192kg |
| A6Plus | 6100×2500mm | 100m/min | 1.5G | 100mm, 2 tools Manual | ±0.05mm/m | ±0.03mm | 1500-6000W: 2992kg 12000W: 3595kg |
| A8 | 8050×2500mm | 100m/min | 1.5G | 100mm, 2 tools head | ±0.05mm/m | ±0.03mm | 3930kg(1000-6000W) 4716kg(12000W) 6319kg(20000W) |
| A12 | 12500×2600mm | 100m/min | 1.5G | 100mm, 7 axis head | ±0.05mm/m | ±0.03mm | 6384kg(6000W) 7651kg(12000W) 10215kg(20000W) |
| A14 | 14000×3100mm | 100m/min | 1.5G | 100mm, 2 axis Head | ±0.05mm/m | ±0.02mm | 12644kg |
